Kodicom 4400

[yaguarcito]

I have a 4400 Kodicom card with 4 bt878 chip, the problem is that ZoneMinder version 1.24.2 does not recognize the cameras installed.
In /etc/modprobe.d/bttv.conf I have the following configuration.

Code: Select all

~ $ More / etc / modprobe.d / bttv.conf

gbuffers options bttv card = 133,132,133,133 = 16

[bb99]

ZM doesn't deal with the camera's at all when you have a capture card interface. ZM deals with the card only and the card with the camera's. First thing to do id set all your functions to none except one (use /dev/video0 channel 0). Once you get it working, all other camera's on the chip be configured exactly the same. For your source tab use: /dev/video0, channel 0, grey scale (gray), 320*240 (for NTSC). If this doesn't help out then you will need to post all your monitor settings and whether or not you're using mmap or shared memory config.

Might be a helpful link: http://www.zoneminder.com/wiki/index.php/Kodicom_4400r
